Product Photo
24 Inch / 600 mm
Embroidery UV DTF Printer
Produce detailed, colourful embroidery-style transfers without digitising traditional embroidery artwork.
Price available on request
Key Benefits
- Embroidery-style effects with fine visual detail
- No embroidery digitising required
- Easy transfer workflow that saves production time
- Suitable for different fabrics and garment products
- Durable and washable output
Embroidery Print Samples
Technical Specifications
| Model | M604 |
|---|---|
| Printer Type | Embroidery-effect UV DTF printer |
| Print Width | 600 mm / 24 inches |
| Print Heads | 3 heads – Epson i3200-U1 or TX800 configuration (confirm supplied configuration) |
| Printing Speed | 4 pass: approx. 12 m²/h; 6 pass: approx. 8 m²/h; 8 pass: approx. 5 m²/h |
| Media | UV DTF media |
| Ink | UV ink |
| Print Technology | VSD technology with intelligent exclusion print function |
| Heating System | Pre/post heater with separate control |
| RIP Software | MainTop 6.0 / PrintFactory / PhotoPrint |
| Operating System | Windows |
| Interface | USB 2.0 |
| Power | AC 110/220V, 50/60Hz |
| Working Temperature | 20°C-35°C |
| Humidity | 35%-65% RH |
| Machine Dimensions (L x W x H) | 1785 x 790 x 1613 mm |
| Packing Dimensions (L x W x H) | 2100 x 970 x 730 mm |
| Package Weight | Approx. 220 kg |
| Applications | Embroidery-effect transfers for garments and fabric products |
Configuration note: The catalogue lists Epson i3200-U1 or TX800 head configurations and also references 300 mm sizing. Confirm the exact supplied 24-inch configuration before order confirmation.
Suitable Applications
T-shirts & Garments
Fashion Fabrics
Custom Merchandise
Decorative Textile Prints
Questions & Answers
Does artwork require embroidery digitising?
The catalogue states that embroidery digitising is not required for this print workflow.
Can it create different embroidery styles?
Yes. The supplied material highlights detailed printing with different embroidery-style visual effects.
Which printhead configuration is supplied?
The catalogue references 3 Epson i3200-U1 or TX800 heads. The final head configuration must be confirmed before ordering.
Is the result washable?
The supplied material describes the output as durable and washable. Final durability depends on media, ink, application and wash conditions.
